Zhejiang Waxing Electromechanical Co., Ltd is one of the most professional manufacturers and suppliers of self lubricating bushing slide bearing in China. Welcome to buy high quality customized bearings made in China here from our factory. For price consultation, contact us.
Quick Details
Type:
Sliding
Applicable Industries:
Manufacturing Plant
Brand Name:
WXING
Model Number:
DEVA-BM
Place of Origin:
SHANDONG, China
Bimetallic:
DEVA BM
Segmented containers and molds:
Self lubrication bearing
Material Capabilitie:
Bronze,Steel Alloys
self-lubricating bearing materials:
deva
Supply Ability
Supply Ability:
400 Set/Sets per Month
Packaging & Delivery
Port
shanghai
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 15 To be negotiated
|
No. |
Properties |
Data |
|
|
1 |
Max.permissible load |
Static(N/mm2) |
310 |
|
Dynamic (N/mm2) |
150 |
||
|
2 |
Max.sliding speed(m/s) |
0.5 |
|
|
3 |
Max.Pv( N/mm2×m/s,dry) |
1.5 |
|
|
4 |
Friction coefficient(dry) |
0.15 |
|
|
5 |
Temperature range(°C) |
-195~320 |
|
|
6 |
Compressive strength(N/mm2) |
310 |
|
|
7 |
Tensile strength(N/mm2) |
315 |
|
|
8 |
0.2% Yield strength(N/mm2) |
220 |
|
|
9 |
Bond strength Max load(kN) |
12.877 |
|
|
10 |
Brinell hardness(HB) |
>45 |
|
|
11 |
Density(g/cm³) |
6.7 |
|
| size | Customized according to customer requirements |
| MOQ | 1 piece can be customized |
| Delivery | Usually within 15 days after payment |
| service life period | According to the purpose 3-5year |
| quality assurance | 1 year |
| lubricating material | graphite,PTFE,Mos2 |
| Metal material | copper |
| Sample | Free sample |
Material properties:
The self-lubricating composite sliding material is a bearing material with the sintered wear resistance layer as the sliding surface and the metal back. The sintered layer is a special bronze alloy with uniformly dispersed sloid lubricants such as the graphite,PTFE,Mos2. When the relative movement of the working surface occurs,a continous lubricating film will be rapidly generated to protect the contacting surfaces from wearing and friction.
| Advantages of our materials |
| 1.Can help customers reduce costs |
| 2.High temperature resistant, can be used in peak environment |
| 3.Can be welded |
| 4.Self lubricating |
| 5.No friction damage to the coupling |
