With the support of professional technical inspectors and perfect testing methods, we ensure the stable and excellent quality of our 21315 Chrome Steel Spherical Roller Bearing, Europe Chrome Steel Thrust Ball Bearing, Linear Bearing Rail LM25UU Rubing Matching Bearing. We put the public at the center, care for the society, and obtain the praise and support of the public. Under the condition of market economy, we can adjust the development strategy according to the local conditions. It is the company's long-term development policy to pay attention to product quality and technology investment.
Quick Details
Structure:
Spherical
Type:
Roller
Applicable Industries:
Machinery Repair Shops, Retail
Brand Name:
WXing or OEM
Model Number:
22230
Precision Rating:
P0 P6 P5
Seals Type:
Open
Number of Row:
Double Row
Place of Origin:
shandong, China
Material:
Chrome Steel GCR15
Clearance:
C0,C1,C2,C3,C4,C5
Certificate:
ISO9001
name:
spherical roller bearing
Main market:
USA and European
Hardness:
61-65HRC
Supply Ability
Supply Ability:
2000000 Piece/Pieces per Month spherical roller bearing
Packaging & Delivery
Packaging Details
1. Industrial Exporting Package with anti-tarnish paper/Carton/Pallet
2. Individual Paper Box/Carton/Pallet
3. As the clients' requirement
Port
Qingdao
Most spherical roller bearings are designed with two rows of rollers, allowing them to take very heavy radial loads and heavy axial loads. There are also designs with one row of rollers, suitable for lower radial loads and virtually no axial load. These are also called "barrel roller bearings" or "Tonnenlager" and are typically available in the 202- and 203-series.
| Bearing No. | Boundary dimensions | Basic load ratings(kN) | Limiting speeds | Mass | |||||
| mm | Dynamic | Static | rpm | Kg | |||||
| d | D | B | rs min | Cr | Cor | Grease | Oil | ||
| 22205 | 25 | 52 | 18 | 1 | 36.5 | 36 | 6,500 | 10,000 | 0.186 |
| 22206 | 30 | 62 | 20 | 1 | 49 | 49 | 5,700 | 8,800 | 0.287 |
| 22207 | 35 | 72 | 23 | 1.1 | 69.5 | 71 | 4,900 | 7,500 | 0.446 |
| 22208 | 40 | 80 | 23 | 1.1 | 79 | 88.5 | 4,300 | 6,600 | 0.526 |
| 22209 | 45 | 85 | 23 | 1.1 | 82.5 | 95 | 3,800 | 5,900 | 0.584 |
| 22210 | 50 | 90 | 23 | 1.1 | 86 | 102 | 3,500 | 5,300 | 0.63 |
| 22211 | 55 | 100 | 25 | 1.5 | 118 | 144 | 3,200 | 4,900 | 0.808 |
| 22212 | 60 | 110 | 28 | 1.5 | 115 | 147 | 2,900 | 4,500 | 1.15 |
| 22213 | 65 | 120 | 31 | 1.5 | 143 | 179 | 2,700 | 4,200 | 1.5 |
| 22214 | 70 | 125 | 31 | 1.5 | 154 | 201 | 2,500 | 3,900 | 1.55 |
| 22215 | 75 | 130 | 31 | 1.5 | 166 | 223 | 2,300 | 3,600 | 1.65 |
| 22216 | 80 | 140 | 33 | 2 | 213 | 277 | 2,200 | 3,400 | 1.99 |
| 22217 | 85 | 150 | 36 | 2 | 251 | 320 | 2,100 | 3,200 | 2.49 |
| 22218 | 90 | 160 | 40 | 2 | 292 | 385 | 1,900 | 3,000 | 3.24 |
| 22219 | 95 | 170 | 43 | 2.1 | 294 | 390 | 1,800 | 2,800 | 4.1 |
| 22220 | 100 | 180 | 46 | 2.1 | 315 | 415 | 1,700 | 2,700 | 4.95 |
| 22222 | 110 | 200 | 53 | 2.1 | 410 | 570 | 1,600 | 2,400 | 7.2 |
| 22224 | 120 | 215 | 58 | 2.1 | 485 | 700 | 1,400 | 2,200 | 9.1 |
| 22226 | 130 | 230 | 64 | 3 | 570 | 790 | 1,300 | 2,000 | 11.2 |
| 22228 | 140 | 250 | 68 | 3 | 685 | 975 | 1,200 | 1,900 | 14 |
| 22230 | 150 | 270 | 73 | 3 | 775 | 1,160 | 1,100 | 1,700 | 18.1 |
| 22234 | 170 | 310 | 86 | 4 | 1,000 | 1,520 | 980 | 1,500 | 28 |
| 22236 | 180 | 320 | 86 | 4 | 1,040 | 1,610 | 920 | 1,400 | 29.3 |
| 22238 | 190 | 340 | 92 | 4 | 1,160 | 1,810 | 860 | 1,300 | 36.6 |
| 22240 | 200 | 360 | 98 | 4 | 1,310 | 2,010 | 820 | 1,300 | 44 |
| 22244 | 220 | 400 | 108 | 4 | 1,580 | 2,460 | 730 | 1,100 | 60.4 |
| 22248 | 240 | 440 | 120 | 4 | 1,940 | 3,100 | 660 | 1,000 | 81.7 |
| 22252 | 260 | 480 | 130 | 5 | 2,230 | 3,600 | 610 | 930 | 106 |
| 22256 | 280 | 500 | 130 | 5 | 2,310 | 3,800 | 560 | 860 | 112 |
| 22260 | 300 | 540 | 140 | 5 | 2,670 | 4,350 | 510 | 790 | 141 |
A spherical roller bearing is a rolling-element bearing that permits rotation with low friction, and permits angular misalignment. Typically these bearings support a rotating shaft in the bore of the inner ring that may be misaligned in respect to the outer ring. The misalignment is possible due to the spherical internal shape of the outer ring and spherical rollers.[1] Despite what their name may imply, spherical roller bearings are not truly spherical in shape. The rolling elements of spherical roller bearings are mainly cylindrical in shape, but have a profile that makes them appear like cylinders that have been slightly over-inflated.
We strive to provide our customers with Made in China Spherical Rolling Bearings 22228 22228c 22228K 22228ck 22228cc/W33 22228cak ... of better cost performance, better quality and more comprehensive services to improve their productivity and competitiveness. In terms of product selection and after-sales service, customers can enjoy professional services. The company comprehensively promotes standardized procedural management.
